The High Range AFM probe monitors air flows from 500 to 2500 feet per minute (FPM) (150 to 760 meters per minute).
  • Air Flow Range: 500 – 2500 FPM (150 to 760 meters per minute)
  • RJ11 4-conductor phone jack connection to Air Flow Monitor controller
Unit of Measure

Technical Specs

Brands

 N/A Hampshire Controls

Air Flow Range

 N/A High 500 to 2500 fpm150 to 760 m/min

Sensor and Probe

Diameter

 N/A 5/16 in

Sheath Length

 N/A 7.5 in

Lead Length

 N/A 10 ft

Features

N/A

  • Extensive air flow range covered with low range (50 to 500 FPM) and high range (500 to 2500 FPM) probes
  • Audible and visual alert status indicators
  • Relay contact output to activate central alarm systems and automatic notification systems
  • Easily accessible probe, power, and relay connections

Available Options

N/A

  • Low Range (LR: 50 to 500 FPM) or High Range (HR: 500 - 2500 FPM)
  • On-demand 6-minute audible alarm muting
  • Adhesive VELCRO® mounting or interlocking wall mounting bracket
